T7000-A-DI HIGH PRECISION DIGITAL OUTPUT DUAL-AXIS INCLINATION SENSOR

T7000-A-DI HIGH PRECISION DIGITAL OUTPUT DUAL-AXIS INCLINATION SENSOR
  1. Product characteristics

T7000-A-DI is a high-precision dual axis tilt sensor launched by Micro-Magic Inc, with a resolution of 0.0007 °, an accuracy of 0.005 °, and a temperature drift of 0.0007 °/℃. Output interfaces RS232, RS485, RS422, TTL, Modbus, CAN bus are optional.

The product is equipped with high-precision digital sensors from ADI, which can correct the temperature drift of the sensor based on the monitoring temperature changes of the built-in temperature sensor, ensuring the repeatability of the product in low and high temperature environments. Output corresponding frequency of 100Hz. The product is a truly industrial grade product with reliable and stable performance, good scalability, and multiple output options; Suitable for application in various industrial control environments.

  1. Product performance
  • Dual-axis inclination monitoring (single-axis optional)
  • High vibration resistance >20000g
  • Output frequency 5-100Hz (optional)
  • Measuring range: ±0~±5°/±10°/±15°/±30°(optional)
  • Output : RS232/RS485/TTL/RS422/CAN

( optional)
  • Baud rate 2400~115200 (optional)
  • Wide voltage input: DC11~36V
  • Widely operating temperature: -40～+85℃
  • Product size: 107*55.5*27mm (can be customized)
  • Protection level: IP67
  1. Product application
  • Railway gauge ruler, gauge leveling
  • Precision laser platform equipment
  • Bridge, dam monitoring
  • Tilt based monitoring
  • Precision machine tool horizontal control
  • Satellite solar antenna positioning
  • Gimbal leveling
  • Medical equipment
  • Ship navigation attitude measurement
  • Angle control of various construction machinery
