T700-A-CA CANOPEN OUTPUT DUAL-AXIS INCLINATION SENSOR

1. Product characteristics FULL DATA SHEET ON DEMAND

T700-A-CA is a CANOPEN output dual axis tilt sensor developed by Micro-Magic Inc for industrial field control. It uses an industrial standard isolator CAN transceiver and a high-precision 16 bit A/D differential converter. Through an n-order filtering algorithm, it can measure the tilt and pitch angles of the sensor output relative to the horizontal plane.

The product is equipped with a high-precision temperature sensor from ADI, which can correct the temperature drift of the sensor according to the changes in the built-in temperature sensor, ensuring high repeatability of the product in low and high temperature environments. The output response frequency standard can reach 100Hz, suitable for various harsh industrial control environments.

2. Product performance

- Dual-axis tilt monitoring (single-axis optional)	- High vibration resistance: >20000g
- Measuring range: ±0～±90° (optional)	- Accuracy: 0.02°; High resolution: 0.001° - Baud rate 100K~500K bps (adjustable)
- Output mode: CANopen - Voltage input: 9~36V (5V optional) - Small size: 904026mm (can be customized)	- Wide temperature operation -40~+85 ℃ - Protection level: IP67 (IP68 can be customized)
-	-

3. Product application

- Railway gauge ruler, gauge instrument leveling

- Bridge and dam monitoring

- Precision machine tool horizontal control

- Fan oscillation posture

- Measurement of ship navigation posture

- Signal tower, high-voltage power line tower

- Robot tilt monitoring

- Satellite solar antenna positioning

- Medical equipment

- Angle control of various construction machinery
