T70-C-AC 4-20MA CURRENT OUTPUT TYPE SINGLE-AXIS INCLINATION SENSOR

T70-C-AC 4-20MA CURRENT OUTPUT TYPE SINGLE-AXIS INCLINATION SENSOR

  1. Product characteristics  (FULL DATA SHEET ON DEMAND)

T70-C is a small size single-axis current output inclination sensor developed by Micro-Magic Inc. The output current is 4~20mA, 0~20mA, 0~24mA optional. Due to the built-in inclination unit of the latest micro-electromechanical production technology, it is small in size and low in power consumption.

The working temperature reaches the industrial level -40~+85℃. The long-distance transmission can reach more than 2500 meters. It has strong anti-electromagnetic interference ability and can be adapted to the environment. Long-term work in harsh industrial environments.

This product adopts the non-contact measurement principle and can output the current attitude and inclination angle in real time with an accuracy of up to 0.1°. It is simple to use and does not require retrieval of the relative changes in the two-sided installation. It is an ideal choice for industrial equipment and platform posture measurement!

  1. Product performance
  • Single-axis tilt monitoring
  • High vibration resistance: >3500g
  • Measuring range:

0-±180° (0-360°) optional
  • Accuracy: 0.1°; High resolution: 0.01°
  • Output mode: 4~20mA, 0~20mA, 0~24mA optional, RS232 and RS485 optional at the same time
  • Relative/absolute zero setting
  • Voltage input: DC9~36V
  • Widely operating temperature: -40～+85℃
  • Small size: 90*40*26mm (can be customized)
  • Protection level: IP67 (IP68 can be customized)
  1. Product application
  • High-voltage power line tower monitoring
  • Satellite solar antenna positioning
  • Aerial work vehicles
  • Medical equipment
  • Pan/tilt leveling
  • Angle control of various construction machinery
  • Monitoring based on tilt/inclination sensor
  • Bridge and dam monitoring
  • Mining machinery, oil drilling equipment
