Product characteristics ( FULL DATA SHEET ON DEMAND )
The T7-B-2 series is a digital small volume MEMS photovoltaic tracking inclinometer launched by Micro-Magic Inc, with a maximum measurement angle range of single axis 360 °, accuracy of 0.1 °. Due to the built-in MCU control system, the sensor output linearity is corrected twice, compensating for the accuracy decrease caused by insufficient correction in analog models.
Adopting non-contact measurement of the original quantity, it can output the current attitude inclination in real time, and is simple to use without the need to retrieve the relative changes of the two surfaces for installation.
It is industrial automation control, wind deviation monitoring, inclination measurement, horizontal adjustment, vertical monitoring, and attitude recording; Engineering machinery, surveying and mapping instruments, etc. All adopt industrial devices, with stable and reliable performance; Anti impact, anti-vibration, suitable for long-term operation in harsh industrial environments.
-
Product performance
|
|
-
Large range, high value performance
|
|
|
-
Accuracy: 0.1°; High resolution: 0.01°
|
-
Output mode: RS232/RS485/RS422/TTL /CAN (Optional)
|
-
Small size, light weight, and easy integration
|
-
Voltage input: DC +5V (DC 9-36V customized)
|
-
Widely operating temperature: -40～+85℃
|
-
Small size: 55*37*24mm (can be customized)
|
-
Protection level: IP67 (IP68 can be customized)
|
-
Product application
-
Photovoltaic angle tracking system
-
Bridge and dam monitoring
-
Precision machine tool horizontal control
-
Fan oscillation posture
-
Measurement of ship navigation posture
|
-
Signal tower, high-voltage power line tower
-
Robot tilt monitoring
-
Satellite solar antenna positioning
-
Medical equipment
-
Angle control of various construction machinery
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
