G830 HIGH PRECISION CURRENT OUTPUT ANGLE SENSOR (ABSOLUTE VALUE ENCODER, ANGULAR DISPLACEMENT SENSOR)

1. Product characteristics

The G830 series is high precision angle sensor, with an accuracy of 0.02°, supporting setting range and adopting integrated MEMS technology, low power consumption, built-in high-precision 16 bit A/D converter, multiple outputs RS232, TTL, RS485, RS422, CAN, 0-5V, 0-10V, 4-20mA, 0-20mA and 0-24mA are optional.

By utilizing magneto electric induction technology, precision bearings, differential array magnetic sensitive components, and non-contact measurement of the shaft, the parallel magnetic field strength of a permanent magnet installed at one end of the shaft is sensed and processed by MCU. Linear correction, temperature compensation, self-developed filtering algorithm, and programmable intelligent control with multiple different slope settings are implemented to improve measurement accuracy.

All products undergo calibration, reverse and anti pulse peak voltage protection, and long-term aging stability testing before leaving the factory. Each process is precise and rigorous, ensuring reliability under different working conditions and long-term use cycles; Featuring non-contact, long lifespan, high resolution, low temperature drift, excellent linearity, precise reset, high frequency response, multiple protections, anti-interference, vibration and impact resistance, suitable for various harsh industrial environments such as water, oil, and gas, it is a cost-effective angle sensor. It is also an ideal product for the upgrading of contact type angle sensors, such as conductive plastic potentiometers, encoders, and angular displacement sensors.

2. Product performance

3. Product application
