1. Product characteristics
The ACM-1000 vibration sensor is independently developed and produced by Micro-Magic Inc, using digital filtering technology to effectively reduce measurement noise and improve measurement accuracy. It can be applied to multiple fields such as vibration testing, impact testing, and shock testing. The product consists of a monocrystalline silicon capacitive sensor, a temperature sensor, and a solid-state power supply (overvoltage protection); The design features sturdy structure, low power consumption, and excellent bias stability, ensuring output reliability. Multiple output RS232/485/TTL/RS422/CAN buses are available, and different address codes can be set. Multiple sensors can be used in series over long distances, facilitating multi-point measurement and data analysis.
It can directly output the three-axis vibration speed, angle, amplitude (displacement), frequency, and temperature of the object to determine whether the measured object (bridge, fan, bearing vibration measurement and real-time monitoring of rotating machinery) is damaged, making it convenient for users to analyze data. For example, machine failures caused by factors such as shaft system failures (blade wear, dynamic imbalance, poor alignment), bearing failures (bearing damage, poor lubrication, bearing collision damage, bearing looseness), and transmission failures (gear wear, belt wear, coupling wear, gear pitting and peeling) can be detected in advance by vibration sensors to raise an alarm, preventing the machine from continuing to work in poor conditions and causing damage.
2. Product performance
- Tri-axis (X, Y, Z) optional - Output mode: RS232/RS485/TTL/RS422/Modbus optional
- Baud rate 2400-115200 can be set - Widely operating temperature: -40～+85℃
- Voltage input: DC 9~36V (DC 5V can be customized) - Installation with magnetic suction
- Range: Velocity (0-50mm/s), Angle (0-180 °), Amplitude (displacement 0-30mm), Frequency (1-100Hz) - Size: (44*44*33mm) (can be customized)
- Protection level: IP67 (IP68 customized)
3. Product application
- Vibration measurement of mechanical bearings - Roller
- Bridge and building vibration measurement - Fans and generators
- Free fall
- Crash records, fatigue warning monitoring - Railway track monitoring
- Roadbed analysis and high-speed railway fault detection
|
