G801-B CURRENT OUTPUT ANGLE SENSOR (ABSOLUTE VALUE ENCODER, ANGULAR DISPLACEMENT SENSOR)

1. Product characteristics

The G801-B series angle sensor adopts MEMS technology and magnetoelectric induction technology. It uses differential array magnetic sensitive elements and non-contact measurement of the rotating shaft. It senses the parallel magnetic field intensity of the permanent magnet installed at one end of the rotating shaft and performs linearity correction through MCU processing, temperature compensation, output signal standardized digital filtering, zero point setting, programmable intelligent control of multiple different slope settings, to achieve the absolute angular position of the output sensor within the range of 0 ~ 360°. Accuracy 0.2°, output RS232, RS485, CAN, 0-5V, 0.5-4.5V, 0-10V, 4-20mA, 0-20mA optional.

Before leaving the factory, all products undergo calibration, reverse and anti-pulse peak voltage protection, and long-term aging stability testing. Each process is precise and rigorous, ensuring reliability under different working conditions and long-term use cycles; Featuring non-contact, long lifespan, high resolution, low-temperature drift, excellent linearity, precise reset, high-frequency response, multiple protections, anti-interference, vibration and shock resistance, suitable for various harsh industrial environments such as water, oil, and gas, it is a high cost-effective angle sensor. It is also an ideal product for updating and upgrading contact angle sensors (such as conductive plastic potentiometers, encoders, and angular displacement sensors).

2. Product performance

3. Product application
