C9-A 40° TILT ANGLE COMPENSATION CAN PROTOCOL OUTPUT 3D ELECTRONIC COMPASS

1. Product characteristics (FULL TECHNICAL DATA SHEET ON REQUEST)

C9-A is a high-precision 3D electronic compass with CAN protocol interface launched by Micro-Magic Inc, which introduces advanced 3D compensation patent technology from the United States, allowing accurate heading data to be provided even at a product tilt angle of ± 40 °.

The product has a small size, low power consumption, and can be applied in many fields such as antenna stability, vehicles, and system integration. Its high seismic resistance and reliability also enable the compass to work normally in extremely harsh environments, making it more suitable for today's miniaturized high-precision measurement and integrated control systems.

2. Product performance - Heading 0-360 °, tilting range±40° Heading accuracy 1 ° (RMS), inclination accuracy 0.15 ° - Algorithm compensation with hard magnetic, soft magnetic, and tilt angle - Voltage input: DC +5V (DC +9~36V can be customized) - Output mode: CAN/CANOpen optional - Working current: 40mA - Widely operating temperature: -～40+85℃ - Protection level: IP67 (IP68 customized) - Size: (55*37*24mm) (can be customized)

3. Product application - Individual combat equipment - Accurate laser platform equipment - Petroleum geological logging - Unmanned aerial vehicles - Underwater navigation - Based on inclination monitoring - Marine survey - Satellite solar antenna positioning - Ship navigation attitude measurement - Navigation GPS navigation
